Energy distribution widget

In this article you will learn how to use and configure the energy distribution widget.

The energy distribution widget shows the difference between energy A and energy B. For example, widget can be used to calculate the difference in energy between meter(s) used to track heat production and meter(s) used to track heat consumption.

You can display the value as numerical or in percentage in case you want to display energy losses. You can name the widget, select the unit to be displayed, set custom decimal precision, enable or disable timestamp of latest measurement and set the refresh time of the widget (1-3hours). To configure the meter groups click "Configure" under "Group 1" or "Group 2". Select the devices where the meters are connected to and in the last step of the configuration select the meters from the devices for each group. To set the time period for the energy calculation click "Period" under "Group 2" and select the time period .
